TF4 In-Tank Filter Assembly

Ideal for installation on the return line to remove contaminant ingested or generated by the system

Max Operating Pressure: 100 psi (6.9 bar)



Download Brochure

Elements that go beyond industry standard.

Hy-Pro’s DFE rated G8 dualglass elements are rated to assure performance even when exposed to the toughest conditions that hydraulic systems can generate. Designed to provide the best filtration and ease of use, the HP4C coreless element gives you more options for disposal, meaning you improve your environmental impact and your bottom line.

Works with your system.

Available with one or two inlet ports (180° orientation) for maximum flexibility of installation, you’ll be amazed at how easily the TF4 integrates into your system. For applications requiring AIAG HF4 automotive standards compliance, the H4 special option incorporates the HPK filter element to ensure you meet compatibility requirements and exceed efficiency expectations.

Minimize the mess.

With most of the assembly inside the reservoir, the top loading housing on the TF4 provides easy and clean access when servicing or changing the element. To top it off, keyways on the twist open cover require only loosening of the bolts to access the element so lost parts during service becomes a thing of the past.
