3 min read

DFE: Testing Filters Under Real-Life Conditions (Part 4 of 4)

By Jim Harlan on Tue, Jul. 18, 2017

Throughout the first three entries in this series (find parts one, two and three), we've discussed the difference in two filter element testing methods, ISO16889 and DFE. We've also illustrated how many elements fall short of their stated beta ratio under dynamic flow conditions. Today we'll wrap it up with simulated cold-start tests.

DFE Multi-Pass: Cold Start Contamination Retention

Once the element has captured enough contaminant to reach approximately 90% of the terminal ΔP (dirty filter indicator setting), the main flow goes to zero and the injection system is turned off for a short dwell period. Then the main flow goes to maximum element rated flow accompanied by real-time particle count to measure retention efficiency of the contaminant loaded element. The dynamic duty cycle is repeated to further monitor the retention efficiency of the filter element after a restart.

Topics: ISO 16889 case study filter performance filter elements
4 min read

DFE: Testing Filters Under Real-Life Conditions (Part 3 of 4)

By Jim Harlan on Tue, Jul. 11, 2017

Last week we covered the differences between the ISO16889 Filter Test Procedure and the DFE Filter Test Procedure. This week we illustrate the difference between elements engineered to retain particles during dynamic flow conditions and those that are engineered only to pass the ISO16889 test. (Looking for previous posts? Find parts one, two and four.)

Topics: ISO 16889 case study filter performance filter elements
2 min read

DFE: Testing Filters Under Real-Life Conditions (Part 2 of 4)

By Jim Harlan on Tue, Jun. 27, 2017

Last week, in part one, we briefly discussed how filter elements are rated by manufacturers. This week we're discussing the industry standard ISO16889 multi-pass test and Hy-Pro's standard, the DFE test. (Already read part two? Read parts three and four.)

Current Filter Performance Testing Methods

To understand the need for DFE, it is important to understand how filters are currently tested and validated. Manufacturers use the industry standard ISO16889 multi-pass test to rate filter efficiency and dirt-holding capacity of filter elements under ideal lab conditions.

Figure 1 depicts the test circuit where hydraulic fluid is circulated at a constant flow rate in a closed-loop system with on-line particle counters before and after the test filter. Contaminated fluid is added to the system at a constant rate. Small amounts of fluid are removed before and after the filter for particle counting to calculate the filter efficiency (capture). The capture efficiency is expressed as the Filtration Ratio (Beta) which is the relationship between the number of particles greater than and equal to a specified size (Xμ[c]) counted before and after the filter. In real-world terms, this test is the equivalent of testing a filter in an off-line kidney loop rather than replicating an actual hydraulic or lube system. It’s basically a filter cart test.

Topics: ISO 16889 case study filter performance filter elements
3 min read

DFE: Testing Filters Under Real-Life Conditions (Part 1 of 4)

By Jim Harlan on Tue, Jun. 20, 2017

The Dynamic Filtration Efficiency (DFE) Test is Hy-Pro's standard for testing filter elements. Throughout this four-part series  (find parts two, three and four) we'll discuss what it is, why it matters and why elements engineered with this test in mind outperform others in real-life applications.

First, let's start with the basics.

Why are filters used? How are they rated?

All hydraulic and lube systems have a critical contamination tolerance level that is often defined by -- but not limited to -- the most sensitive system component such as servo valves or high-speed journal bearings. Defining the ISO fluid cleanliness code upper limit is a function of component sensitivity, safety, system criticality and ultimately getting the most out of hydraulic and lube assets.

Topics: ISO 16889 case study filter performance filter elements
5 min read

[Video] Your Lab Reports Are Probably Wrong -- Here's How To Save Them

By Scott Howard on Tue, Aug. 16, 2016

When looking at a lab report, it is assumed the information on the report is accurate. A certified lab will not usually make an error in the report, but if so, it is obvious and easily fixed. Ever hear the saying "By the time the lab gets the report the error has already been made"? For the most part, this is true. Where people are led off course is believing the particle count on the lab report is the gospel. This is natural, but unfortunately not always the case with a bottle sample unless you already employ the techniques listed in the video below.
Topics: contamination ISO 16889 ISO 4406 samples video lab
4 min read

Glass or Cellulose Filter Media?

By Aaron Hoeg on Mon, Sep. 17, 2012

Glass or Cellulose: Which Hydraulic Filter Media is Best?

There are several distinct differences between glass and cellulose media. Media selection should be based on the required cleanliness and other unique needs of the system. Evaluate the Beta ratio (efficiency), dirt holding capacity, flow versus pressure drop characteristics, etc. A hydraulic filter supplier should be able to supply more detailed test information in addition to what is supplied in the literature.

Topics: hydraulic fluid ISO 16889 cellulose media filter elements filter comparison glass media
